Vivun keittoryhmän osat

La Pavoni connecting rod. Return to the La Pavoni P-90/P-91/P-1/P-3 lever group parts overview

Bezzera spring rod

La Cimbali Piston axle. This axle connects the fork lever of the group with the piston shaft. On the outsides of the la cimbali piston axle there are 2 bearings to make the pull action smoother.

Faema retention valve body Return to the Faema Zodiac lever parts overview

Also with the Faema Zodiac groups it is possible that your piston shaft needs replacing, if for instance your lever pin has worn out the attachment hole and there is play on it. Keep in mind that not all piston shafts are interchangeable due to the length of these shafts. This specific shaft has a length of 183mm, this does also include the threads. The...

On this product page you will find the connection between the lever and the lever group itself. In the top of this casted item you will screw the lever itself.  There are 2 holes. 1 of them has a bushing inside so that there is some axial movement possible. In the fixed hole goes the bearing shaft. In the movable hole goes a pin to make a connection with...

The item on this page is a brass piston for La Pavoni and Gaggia lever espresso machine groups. This piston can be used on pre-millennium and millennium brewing groups. In the period between approx. 1996 and 2006 the pistons were made from Teflon. This idea was discontinued after 2006 and they got back to the brass pistons again. The Gaggia part reference...

This cam guide is vital in the lever mechanism used on the old Gaggia lever brewing groups. This cam guide is installed inside the side of the brewing group. The  lever cams do slide over this shaft. This item is not in production anymore.

La Pavoni lever group screwReturn to the La Pavoni P-90/P-91/P-1/P-3 lever group parts overview

La Pavoni boltReturn to the La Pavoni Bar modern parts overview

Rancilio lever cover. Return to the  Rancilio group parts overview

This item is the top section of the lever mechanism used on the Conti lever brewing groups. The Conti part reference on this item is 201800  This chrome plated lever group fork is used to transfer the pulling motion of the lever to a vertical movement. That of the piston. This item has been made from chrome plated brass. This item is available on...

La San Marco lever handle. The lever doesn't come with the handle and top screw. these can be ordered seperatelyReturn to the  San Marco group parts overview

The item on this page you will find a OEM/Original La Pavoni spare part. This nut can be used on La Pavoni pre-millennium and millennium lever brewing groups. This nut is used as a counter nut for the shaft nut. The La Pavoni part reference for this item is 3135264. This nut has a internal M10 thread. The key size for this nut is 14mm. the height of this...

La Cimbali group locking nut. these nuts screw the inner flange of the brewing group to the brewing group itself. Which makes a air and water tight. Return to the La Cimbali lever parts overview

Basically, every lever espresso machine brewing group has a piston shaft and a lever fork, might look different but the idea is the same. These 2 items need to be connected to each other, so that the force can be transferred. That’s why you have a piston shaft pin. This pin is knurled on 1 side. When you install the pin, this knurling will tighten itself...

La Pavoni lever shaftReturn to the La Pavoni P-90/P-91/P-1/P-3 lever group parts overview

Rancilio lever fork. Return to the  Rancilio group parts overview

On this page you will find the lever fork for various lever brewing groups. One of the holes is for the bearing pin hole and the other one is for transferring the puling motion to the vertical spring motion. This specific lever fork is specifically for lever groups which are pre-2001 lever brewing groups. This item is out of production and not available...

This oddly looking screw is the left brewing group pin used on the Vibiemme lever espresso machine brewing groups. The Vibiemme part reference number for this item is VITEPERNGRPIS This screw can only be used on the left side of the brewing group. This group screw is made in Italy. You can use this lever brewing group screw on the lever group used on the...

La Cimbali brewing group stainless steel ball Return to the La Cimbali lever parts overview

The item on this product page is a fork pin. This pin connects the piston shaft and the roller in the back to the piston shaft. This pin can be used on various domestic La Pavoni and Gaggia lever espresso machines. This fork pin can be used on pre-millennium as well on millennium espresso machines. The Gaggia part reference is S3140463 and for La Pavoni...

On this page you will find a chrome plated lever group fork for various lever groups. This fork is responsible for transitioning the lever motion to a vertical motion. This chrome plated group fork can’t be used on the older AL lever groups as used by Astoria and Wega. That part is out of production. This specific item is OEM/Original item suitable for...

On this page you will find a lever fork pin suitable for brands such as the Astoria and Wega. Note, there are more versions available This blank steel pin (so they do rust) is the link between the lever and the piston shaft. This pin has been knurled on one side, this side also grabs into the brass lever group fork. This lever pin is a OEM/Origina (part...

Fiorenzato group casting. this casting holds the lever assembly and the spring and piston assembly, offcourse only the casting. Return to the Fiorenzato lever parts overview

On this page you will find the aluminium lever group cover used in a variety of Faema Lever brewing groups. What is the purpose of this item? Mainly esthetical. But it also prevents dust getting in the brewing group mechanism and the chance also reduces that someone get’s its finger stuck in the bearing mechanism. On what kind of lever brewing groups can...

Conti lever chromed holderReturn to the Conti lever parts overview

La Pavoni lever pinReturn to the La Pavoni P-90/P-91/P-1/P-3 lever group parts overview

The item on this product page is a lip seal or shaft gasket. This seal closes off the piston shaft, but you are still able to move the lever. This shaft gasket van be used on early pre-millennium brewing groups as well on millennium brewing groups. The item can be found on domestic La Pavoni lever espresso machines, as well on Gaggia espresso machines....

It is quite common that the pinion gear on the Gaggia lever brewing group needs to be replaced. This can be from various reasons, like breaking or damaging teeth. This pinion gear is used to lower and raise the piston shaft in the brewing group. The shaft itself is installed in between 2 sealed bearings. Note: these shafts are made from steel so they can...

La Cimbali brass lever group piston. The piston keeps both springs on it's place and guides them. on the top of the piston the piston shaft is screwed into the top. The piston doesn't come with the seals. they can be found thereReturn to the La Cimbali M15 overview page

Faema top valve cap

This oddly looking screw is the right brewing group pin used on the Vibiemme lever espresso machine brewing groups. The Vibiemme part reference number for this item is VITEPERNGRDPI  This screw can only be used on the right side of the brewing group. This group screw is made in Italy. You can use this lever brewing group screw on the lever group used on...

La Pavoni inox ballReturn to the La Pavoni lever group parts overview

The item on this page is a item used on the lever mechanism of various Conti lever brewing groups. The Conti part reference on this item is 202000. This casted brass item is the mid piece of the Conti lever brewing group. This casted piece has 3 bushings installed, this prevents excessive wear on the brass mechanism. You can use this Conti spare part on...

Astoria lever group fork pre 2001 Return to the Astoria lever parts overview
