La Pavonin kumirengas

La Pavoni o-ringReturn to the La Pavoni Bar lever group parts overview

Vipun panimoryhmä käyttää hieman eri osia, sitten normaali pumpun ajama espressokone. Tämä on sama juttu käytettyjen suihkujen kohdalla. Tämä italialaisen IMS Filtri -yhtiön tekemä suihkuruutu on tästä esimerkki. Tämä suihkunäytös kietoutuu panimoryhmän hihnan ympäri pitääkseen sen paikoillaan. Tämän suihkunäytön ulompi halkaisija on 57 mm Tämä suihku on...

On this product page you will find the connection between the lever and the lever group itself. In the top of this casted item you will screw the lever itself.  There are 2 holes. 1 of them has a bushing inside so that there is some axial movement possible. In the fixed hole goes the bearing shaft. In the movable hole goes a pin to make a connection with...

La Pavoni Bar lever group shaftReturn to the La Pavoni Bar lever group parts overview

A variety of espresso machines use a extractable brass sleeve inside the brewing group. This brass sleeve needs to be sealed off. There is a upper and lower seal. The upper o ring seal is the one on this page. This o ring has been made from EPDM. The cord diameter of this o ring is 3,53mm and the inner diameter of this ring is 58,74mm. This specific o...

On this page you will find a plastic handle which goes over a lever brewing group lever. This plastic lever handle can be used with a variety of lever brewing groups such as the ones used with Vibiemme Replica, Astoria Rapallo, La Pavoni Bar, La Pavoni Bart, La Pavoni Pub, Wega Antares, Wega Nova, Victoria Arduino Athena, Brasilia Decurtis AL and so on....

On this page you will find a lever brewing group main spring. This spring is used to generate the pressure. This type of spring is quite common and will find it in a variety of lever espresso machines. This model has a overall length of 140mm and a outer diameter of 46mm. this spring has been made from standard spring steel and after that it got...

On this page you will find a paper shim, these shims are used to fill up the wear of the brewing group and or the wear on the portafilter. This shim is placed above the portafilter gasket itself which makes it possible to make fine adjustments. This portafilter shim has a outer diameter of 66mm a inner diameter of 58mm and a thickness of 0,8mm This paper...
